Item

Unit

XL6230

XL6230C

Table size

mm

1270*300

1370*300

T-slots(NO./width/pitch)

mm

3*14*80

Max table travel - X/Y/Z

mm

720/300/400

1000/380/400

Spindle taper

-

7:24  ISO40

Distance between spindle nose and table surface

mm

100-500

Spindle speed range

r.p.m

11 steps 45-1660

Max swivel angle of milling head

-

360°

Table feed(X/Y/Z)

mm/min

No finite 无级

Table rapid speed

1000/1000/750

Main motor power

Kw

2.2（V）/ 3（H）

Torque of X/Y/Z axis AC servo motor

Nm

10

Overall size

mm

1730*1760*1700

1830*1760*1700
