Specifications

Unit

XK6235

XK6330

Table size

mm

1270x254

1370x305

T-slots(No./width/pitch)

mm

3/16/65

3/16/65

Table travel (X/Y/Z)

mm

750x380x450

750x380x450

Table rapid feed speed(X)

m/min

6

6

Table rapid feed speed(Y)

6

6

Table rapid feed speed(Z)

0.4

0.4

Spindle hole taper

R8

NT40

Distance between spindle and table surface

mm

60-510

60-510

Stroke of spindle quill

mm

127

127

Automatic spindle feed

mm/rev

0-400

0-400

Spindle speed range

r/min

60-4200(variable)

50-3750(variable)

66-4540(16steps)

66-4540(16steps)

Main motor power

HP

3

5

Torque of X/Y/Z axis AC servo motor

N.m

6/6/7

6/6/7

Distance between spindle axis and

Overall size

mm

2000x900x2350

2150x950x2350

Net weight

kg

1700

1800
