Specifications

Unit

5H

Table size

mm

1370x305

Table travel (X/Y/Z)

mm

850X400X450

Spindle taper

NT40

Distance between horizontal nose and table surface

mm

0-460

Spindle speed range

rpm

66-4540

T-slots(No./width/pitch)

mm

3/16/65

Travel of spindle sleeve

mm

127

Feed of spindle sleeve

mm/r

0.04/0.08/0.15

Arm travel

mm

500

Milling head rotation

(FB)45° (LR)90°

Main motor power

5HP

Overall size

mm

1750x1650x2150

Net weight

kg

1350
